Lipo Battery Rechargeable LP052030 3.7V 200mAh Polymer Lithium For Bluetooth

HONG KONG TAC INDUSTRIAL CO., LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
HONG KONG TAC INDUSTRIAL CO., LTD.
Country/Region: China
Tel: 852--51230576,86-020-28991965
Contact Person:
Ms Alice

Lipo Battery Rechargeable LP052030 3.7V 200mAh Polymer Lithium For Bluetooth

Place of Origin : GD.China
Brand Name : Tac
Model Number : LP052030
Certification : UL, Rohs
MOQ : 1000 Blister
Price : USD0.55-0.6
Packaging Details : 5 pcs sample 3days after order Mass order with stock 15days after T/T Without stock 45days
Delivery Time : 14days after order
Payment Terms : T/T, LC, Paypal etc.
Supply Ability : 60K/Day
Type : polymer lithium
Capacity : 200mah
voltage : 37v
circel life : over 500 times
pcb : the battery can pack with pcb
wire : UL1007 26#
Connector : accept
size : 5mm*20mm*30mm
brand : TAC or OEM\ ODM
Contact Now

Lipo Battery Rechargeable LP052030 3.7V 200mAh Polymer Lithium For Bluetooth

Feature:

Model Name; LP052030
Battery Type :polymer lithium-ion battery
Nominal Voltage 3.7V
Nominal Capacity 200mAh
Size :5mm(T)*20mm(w)*30mm(h)

Specification For Lipo Battery Rechargeable LP052030 3.7V 200mAh Polymer Lithium For Bluetooth

No.

Item

Rated Performance

Remark

1

Rated Capacity

Minimum

200mAh

Standard discharge(0.2C C5A)
after Standard charge

2

Nominal Voltage

3.7V

Mean Operation Voltage
During Standard Discharge
After Standard Charge

3

Voltage at end of
Discharge

3.0V

Discharge Cut-off Voltage

4

Charging Voltage

4.2±0.03V


5

AC (1KHz) Impedance
New Cell Max.(mW)

≤150mΩ


6

Standard charge

Constant Current 0.5C5A
Constant Voltage 4.2V
0.01 C5A cut-off

Charge time : Approx 4.0h

7

Standard discharge

Constant current 0.2 C5A
end voltage 3.0 V


8

Fast charge

Constant Current 1C5A
Constant Voltage 4.2V
0.01 C5A cut-off

Charge time : Approx 2.5h

9

Fast discharge

Constant current 1 C5A
end voltage 3.0 V


10

Maximum Continuous
Charge Current

1 C5A


11

Maximum Continuous
Discharge Current

1.5 C5A


12

Operation Temperature Range

Charge: 0~45℃

60±25%R.H.
Be Cell

Discharge: -20~60℃

13

Storage Temperature
Range

Less than 1 year: -20~25℃

60±25%R.H.
at the shipment state

less than 3 months: -20~40℃

14

Weight

Approx :11g

Bare Cell

15

Cell Dimension

Length: Max.30mm

Initial Dimension

Width: Max.20mm

Thickness: Max. 5mm


Application for lipo battery


  1. power tool
  2. digital camera,
  3. the multi-purpose PDA telephones.
  4. Global localization satellite GPS,
  5. Bluetooth, portable type media products(Mp3, Mp4, DVD),
  6. notebook, tablet PC,
  7. the electronic toy,
  8. e-bike, model ship,




Pictures:
High Energy Density Rechargeable LP052030 3.7V 200mAh Polymer Lithium Ion Batteries


High Energy Density Rechargeable LP052030 3.7V 200mAh Polymer Lithium Ion Batteries

High Energy Density Rechargeable LP052030 3.7V 200mAh Polymer Lithium Ion Batteries






more other size for lipo battery

Model

Nominal Voltage (V)

Typical Cap.

Dimension(mm)


v

mAh

Thickness

Width

Height

LP041124

3.7

60

4

11

24

LP361131

3.7

85

3.6

11

31

LP501230

3.7

130

5

12

30

LP451630

3.7

170

4.5

16

30

LP061148

3.7

230

6

11

48

LP582030

3.7

300

5.8

20

30

LP702030

3.7

350

7

20

30

LP632036

3.7

420

6.3

20

36

LP402060

3.7

450

4

20

60

LP802036

3.7

500

8

20

36

LP041422

3.7

90

4.1

14

22

LP041429

3.7

140

4.2

14

29

LP041515

3.7

50

4

15

15

LP031525

3.7

80

3

15

25

LP051621

3.7

120

5

16

21

LP351624

3.7

100

3.5

16

24

LP471958

3.7

480

4.8

19.3

58.5

LP042024

3.7

140

4

19.8

23.5

LP552025

3.7

240

5.5

20.2

25

LP052030

3.7

260

5

20

30

LP052035

3.7

320

5

20

35


Why are you choose TAC BATTERY


  • maoyt assessed 6 years supplier- TAC Battery can be trusted(if for more information ,please find at our homepage.)
  • Payment Terms:T/T ,LC ,Paypal
  • Price Terms:FOB,CIF,EXW
  • Shipping:1.by air 2.by sea 3.by express:UPS,DHL,EMS,TNT.etc with your require
  • provide more professional forward with customer's require
  • Lead Time:7-10 days after receipt of advance payment for the samples, and 25-30 days for OEM ODM order
  • 24-hour online services: FB LINKEDIN TWITTER Whatsapp
  • prompt reply: we are willing to reply asap.
  • competitive price: manufacturer price . level price with your require
  • excellent quality:advance materials,can be recharged for 500 times,with built-in PCM to protect the who circuit.
  • strict quality control: complete QC control system, test the battery with IEC standard
  • CE,ROHS,MSDS,UN38.3 approved and KC BIS with customer's require
